Evaporator Unit 1600W (Mid Temp) IDH-1.6/6

Evaporator Unit 1600W (Mid Temp) IDH-1.6/6

The IDH-2 evaporator unit from the ICEAGE IDH Series is engineered for medium-temperature refrigeration applications. With a 1.6kW cooling capacity and single 300mm axial fan, it provides efficient air distribution and reliable performance in commercial cold rooms, food storage, and processing environments. Designed for ambient conditions up to +10°C and evaporating temperatures around 0°C, this unit ensures consistent cooling and dependable operation.

Features:

• Cooling capacity of 1.6kW at 0 °C evaporating temperature
• Heat exchange surface area of up to 6-8m² for effective thermal transfer
• Single 300mm axial fan delivering (approx) 1560m³/h airflow
• Fin spacing of 4.5mm optimized for mid‑temperature refrigeration
• Inlet/outlet pipe size: 10mm – 12 mm for standard connections
• Defrost heaters rated at 300-400W for both fin and tray sections
• Compact dimensions: 610mm length × 255mm width × 400mm height
• Suitable for cold rooms, food storage, and mid‑temp refrigeration systems
